Core Manufacturing Process
Main Structure
Shield Body Shell: Aluminum alloy CNC machined and acid-etched for an aged look
Cutter Disc Teeth: Zinc alloy precision casting
Hydraulic Piping: Copper tubing hot-bent into shape
Dynamic Components
Rotating Cutter Disc: Micro-reduction motor drive
Extendable Cylinder: Hysteresis extension rod simulation
Tube Segment Boom: Steel wire rope counterweight system
Materials and Surface Treatment
Special Effect Treatment
Cutting Marks: Manually polished with diamond grinding wheels
Hydraulic Oil Stains: Epoxy resin mixed colour paste
Rust Effect: Iron powder oxidation reaction
Colour Scheme
Main colour: Engineering machinery-specific orange-yellow
Warning markings: Fluorescent paint screen printing
Wear areas: Graphite powder dry brushing
Display optimisation design
Detail enhancement
Removable outer shell design
Magnetic geological cross-section display
UV printing of company logo
Maintenance design
Modular circuit system
Quick-release transmission structure
Dust-proof sealing treatment
